Pure diode laser system
- Full color mixing laser with analog color modulation
- Control via master/slave function; ILDA; Cube Laser Control App; stand-alone; DMX
- Integrated show programs
- With mounting bracket
Scope of delivery
- 1 x laser
- 1 x user manual
- 1 x power cord
- 1 x Interlock
- 2 x key
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 20 W |
| IP classification: | IP20 |
| Protection class: | Protection class I |
| Power connection: | Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided) |
| Laser class: | 4 |
| Laser color: | R/G/B |
| Laser module: | Blue (B) 600 mW 450nm Green (G) 520 mW 450nm Red (R) 200 mW 638nm |
| DMX input: | 1 x 3-pin XLR (F) mounting version |
| DMX output: | 1 x 3-pin XLR (M) mounting version |
| Control: | Master/slave function; ILDA; Cube Laser Control App; stand-alone; DMX |
| Housing color: | Black |
| Attachment system: | Mounting bracket |
| Dimensions: | Length: 17 cm Width: 16 cm Height: 13.5 cm |
| Weight: | 2.75 kg |
