JBSYSTEMS MINI LED MANAGER – alimentatore/centralina led

:: Product Description

• Extremely versatile power supply for all kinds of passive RGB LED-projectors.
• Different standalone working modes:
  • Fixed color mode: Instant access to 16 pre-programmed colors
  • Auto chase mode: 16 different color chases with 8 different speeds.
  • Sound chase mode: 16 different color chases with audio triggering
  • Fade chase mode: 16 different color chases fading smoothly at 8 different speeds.
• Any wall-switch can be used to turn the output on/off, even when used in DMX-mode!
• All functions can be controlled:
  • Directly on the on the Mini Led Manager
  • With an optional LEDCON-01 or LEDCON-02 remote
  • With a 300Watt LED Manager
  • By any standard DMX-controller
• Several Mini Led Managers can be used in Master/slave mode to create high power, fully synchronized setups.
• 100Watt power 24Vdc output. (R+G+B) with short-circuit protections
• 4 DMX channels needed: Ch1=red, Ch2=green, Ch3=Blue, Ch4=Dimmer/strobe.
• Enclosure prepared for easy installing against the wall.
• Low noise fan cooling for extra reliability.

:: Technical Information

Power Input:  AC 230V~ 50Hz
Fuse:  3,15A / 250V slow blow (20mm glass)
Backup batteries:  3x 1,2V AA-type NiMH rechargeable batteries (optional)
Output voltage to LEDs:  DC 24V common anode
Output power to LEDs:  1x 100W max
   * Red: 33W max. (Total = 100W max.)
   * Green: 33W max. (Total = 100W max.)
   * Blue: 33W max. (Total = 100W max.)
DMX connections:  3pin XLR (DMX-512 standard)
DMX channels:  4 (CH1: red, CH2: green, CH3:blue, CH4:dimmer/strobe)
Audio input:  None, internal microphone
Size:  218×140×88 mm
Weight:  4,5kg
