TOPP PRO TP TRX500

PREZZO SU RICHIESTA

Amplificatore a 2 canali 1 unita’

SPEDIZIONE GRATUITA

per ordini superiori a 200 €

VUOI PAGARE A RATE?
Contatta Paco 329 2237447

EAN: 8032496631941 COD: TP TRX500 Categoria: NO OWN

Descrizione
Informazioni aggiuntive

Amplificatore a 2 canali 1 unita’

Power bridge mode 8 ohms: 140W
Power stereo mode 4 ohms: 70W x 2
Power stereo mode 8 ohms: 50W x 2

Bridge Mode 8 Ohms

Continuous	140w
Program / Peak	200W / 280W

Stereo Mode 4 Ohms

Continuous	70W x 2
Program / Peak	210W x 2 / 140W x 2

Stereo Mode 8 Ohms

Continuous	50W x 2
Program / Peak	60W x 2 / 100W x 2

Dimension (cm)

59.8 x 49.9 x 12.9

Weight (kg)

9.48

Distortion: (SMPTE-IM):

<0.05%

Frequency Response:

20Hz- 20kHz ±0.1/3dB

Signal to Noise:

20Hz- 20kHz 102dB

Voltage Gain:

40x (32dB)

Input Sensitivity @ 4 ohms:

1Vrms

Input clipping:

10 Vrms (+22dB)

Input Impedance:

10 Kohms unbalanced, 20 Kohms balanced, 56 (36dB)

Controls:

Front: AC Switch, Ch1 – Ch2 Gain Knobs, Rear:Limiter, Bridge Selector

Indicators: (1 per Channel)

Power-On: Blue LED, Protection: Green LED, Limiter : Yellow LED, Clip: Red LED, Parallel-input: Yellow LED

Connectors, each channel:

Input: Terminal Block / Output: Screw-terminal Barrier Block

Cooling:

Continuously variable speed fan, front-to-rear air flow

Load Protection:

On / Off muting, overheat & short circuit protection

Power Supply:

220-240V (110-120V) AC 50-60Hz

Peso	9,48 kg
Codice Ean	8032496631941

TOPP PRO TP TRX500
